What is the diameter of a 4 40 screw?

Fastener and Screw / Bolt Design, Formula and Calculations Screw Size Class Thread Major Diameter 4-40 2A 0.1120 4-40 3A 0.1120 4-48 2A 0.1120 4-48 3A 0.1120 Click to see full answer. Keeping this in consideration, what is the diameter of a #4 screw? US Machine Screw Diameters Size Thread Diameter Decimal Nearest Fractional #4 0.11″ 7/64″ #5 0.12″ 1/8″ #6 0.13″ 9/64″ Subsequently, question is, what is the major diameter of a #4 40 UNC thread? UNC Thread ANSI/ASME B1. 1 Nominal Diameter Major Diameter Inch Major Diameter mm #2 – 56 UNC 0.086 2.184 #3 – 48 UNC 0.099 2.515 #4 – 40 UNC 0.112 2.845 #5 – 40 UNC 0.125 3.175 what size is a 4 40 screw? 4 refers to the diameter of the screw. In the case of the 4-40, it is . 112 inch.What is major diameter of a screw?The major diameter of a thread is the diameter of the imaginary co-axial cylinder that just touches the crest of an external thread or the root of an internal thread. The minor diameter is the diameter of an imaginary cylinder that just touches the roots of an external thread and (or) the crests of an internal thread.
